Installation Guide: Cargo Bicycle Rack Accessory Kit
Tools Needed:
3/16" Allen key (included with your rucRak)
½" wrench
1. Install the Pole Brace
Attach the included brace using the supplied 5/16" x 2" bolts, nuts, and washers.
Tighten using the 3/16" Allen key and ½" wrench.
2. Install the Eyebolts
Thread the four eyebolts into the middle rivnuts on the aluminum pole to create adjustable tie-down points.
3. Prepare the rucRak for Bike Mode
Fold the rucRak basket into the bike-carrying angle.
Insert the side pins to lock the basket into position.
Using a Tailgater Table?
Remove the two knobs and two frame pins holding it in place.
4. Load the Bike
Place the front wheel into the bike slots.
Secure the wheel using the included Softride wheel straps and Velcro fasteners.
5. Install the Support Pole
Insert the padded aluminum pole into the center bracket.
Tighten using the 3/8” studded knob.
Attach the pole to the outer frame using the 5/16” knobs (from your Tailgater Table kit).
6. Strap the Bikes
Use the eyebolts and bungee cords to secure the bike to the pole and frame.
For two bikes:
Face the second bike in the opposite direction.
Strap it using the same technique.
7. Final Securement
Clip the remaining straps to the rear loop locations on the rack for full stabilization.
You now have a fully functional cargo bicycle rack + cargo carrier system.
